Chemical Formula | CuMnNi |
Catalog No. | ST0975 |
CAS Number | – |
Purity | 99.9%, 99.95%, 99.99%, 99.995%, 99.999% |
Shape | Discs, Plates, Column Targets, Step Targets, Custom-made |
Recognized for their outstanding purity and competitive pricing, the Copper Manganese Nickel Sputtering Targets from Stanford Advanced Materials (SAM) demonstrate a commitment to excellence. Leveraging our profound expertise in materials science, we assure exceptional performance and reliability through meticulous craftsmanship in the production of these targets.
Copper Manganese Nickel Sputtering Target is a specialized material used in the process of sputtering, which is a technique for depositing thin films onto substrates. This target is composed of a combination of manganese, nickel, and copper. During sputtering, ions are directed at the target material, causing the release of atoms or particles. These released particles then deposit onto a substrate, creating a thin film. Copper Manganese Nickel Sputtering Targets find applications in various industries, including semiconductor manufacturing, optical coatings, and thin-film technology, where the unique properties of this combination of metals are utilized for specific performance requirements.
Related Product: Manganese Sputtering Target, Manganese Oxide Sputtering Target
Compound Formula | CuMnNi |
Molecular Weight | 230.62 |
Appearance | Silver Metallic Target |
Melting Point | 960-1020℃ |
Density | 8.4 g/cm3 |
Electrical Resistivity | 43-48 µΩ·cm |
Tensile Strength | 300-600 MPa |
Thermal Conductivity | 22 W/m/K |
Available Sizes | Dia.: 1.0″, 2.0″, 3.0″, 4.0″, 5.0″, 6.0″
Thick: 0.125″, 0.250″ |
Our Copper Manganese Nickel Sputtering Target is carefully handled during storage and transportation to preserve the quality of our products in their original condition.
SAM’s Copper Manganese Nickel Sputtering Target is available in various forms, purities, and sizes. We specialize in producing high-purity physical vapour deposition (PVD) materials with the highest possible density and smallest possible average grain sizes for use in semiconductor, chemical vapour deposition (CVD), and physical vapour deposition (PVD) display and optical applications.
